1phase 220V 1000W 1KW 4N.m 2500rpm NEMA34 AC servo motor drive kit 2500p

1phase 220V 1000W 1KW 4N.m 2500rpm NEMA34AC servo motor drive kit 2500ppr with 3m cable

 Package including:

Product	Specification	Quantity
LC 1000w servo motor	LCMT-10L02NB-90M04025B	1
LC 1000w servo drive	LCDB2-103002-LB922	1
Servo power cable	Standard configuration (3m)	1
Servo encoder cable	Standard configuration (3m)	1



If you need the servo motor with brake,please contact with us.

If you need longer cable for this servo system,please write us .we can offer 5m,10m,15m,20m length cables.

Please leave your email address to get theuser manual of the servo driver if you need.



 Lichuan Servo MotorNaming Rules

   LCMT - 02 L 02 N B - 60 M006 30 B



·        LCMT--- Product information

·        02-------- 200W ( 04---400W/  07---750W /  10---1KW )

·        L---------- Motor inertia ( L---low /M---middle )

·        02-------- Sensing form ( 01---line savingencoder 2500     02---15 type encoder 2500 )

·        N---------- Without brake (Z---with brake )

·        B--------- only keyway no oilseal ( A---only oil seal no keyway  C---oil seal and keyway )

·        60-------- Frame size

·        M006---  Torque

·        30-------- Speed

·        B---------  B series ( A--- A series /C--- C series )



Lichuan Servo Driver Naming Rules



    LCDB2 - 02 20 02 - L B 6 22



·        LCDB2-- Product information

·        02-------- Motor power  (02---200W 04---400W /  07---750W /  10---1KW... )

·        20-------- Peak current ( 20---20A / 30---30A/ 50---50A / 75---75A )

·        02-------- Encoder information ( 01---linesaving encoder  / 02---15 type encoder )

·        L---------- Motor inertia ( L---low /M---middle )

·        B---------Driver series (A---A series / B---B series / C---C series )

·        6--------- Frame size ( including 6 /  8  /  9  /  110 ... )

·        22-------- Voltage ( 22---single phase 220v /32---3 phase 220v / 34---3 phase 380v )



1000W servo Motor LCMT-10L02NB-90M04025B Parameters Overviews

Motor Model	LCMT-07M02NB-90M02430B	Brand	Lichuan
Frame Size	86 mm * 86 mm	Motor Length	181 mm
Shaft Diameter	16mm	Driving Voltage	Single / 3 Phase 220V
Rated Torque	4N.M	Rated Speed	2500  RPM
Positioning Accuracy	0.01 mm	Encoder	2500ppr
Weight	4.2kg	Matched Driver	LCDB2-103002-LB922



1000W Servo Driver LCDB2-103002-LB922 Features

1. Power Range: 1kw 1000w

2. Input Voltage: AC 200V-230V , singlephase / 3 phase

3. Position / Speed control mode

4. With MODBUS communicationperformance(RS-485 / RS-422 / RS-232),

   ASCII and RTU communication protocol



5. Encoder: 2500ppr
