P5KPL-VM LGA 775 Intel G31 Micro ATX Intel Motherboard

Model P5KPL-VM Supported CPU
CPU Socket Type LGA 775
CPU Type Core 2 Quad / Core 2 Extreme / Core 2 Duo / Pentium D / Pentium 4 / Celeron D
FSB 1333/1066MHz
Supported CPU Technologies Hyper-Threading Technology Chipsets
North Bridge Intel G31
South Bridge Intel ICH7 Memory
Number of Memory Slots 2×240pin
Memory Standard DDR2 800
Maximum Memory Supported 4GB
Channel Supported Dual Channel Expansion Slots
PCI Express x16 1
PCI Express x1 1
PCI Slots 2 Storage Devices
PATA 1 x ATA100 2 Dev. Max
SATA 3Gb/s 4 Onboard Video
Onboard Video Chipset Intel GMA 3100 Onboard Audio
Audio Chipset Realtek ALC662
Audio Channels 6 Channels Onboard LAN
Max LAN Speed 10/100/1000Mbps Rear Panel Ports
PS/2 2
COM 1
LPT 1
Video Ports D-Sub
USB 1.1/2.0 4 x USB 2.0
Audio Ports 3 Ports Onboard USB
Onboard USB 4 x USB 2.0 Physical Spec
Form Factor Micro ATX
Dimensions 9.6" x 8.0"
Power Pin 24 Pin
