P5N-E SLI Rev1.01G Socket 775 Motherboard 1002

Model
Brand ASUS
Model P5N-E SLI
Supported CPU
CPU Socket Type LGA 775
CPU Type Intel Socket 775 Core™2 Quad/Pentium® Extreme/Pentium® D/Pentium® 4/Celeron Processors
FSB 1333/1066MHz
Supported CPU Technologies Hyper-Threading Technology
Chipsets
North Bridge NVIDIA nForce 650i SLI
Memory
Number of Memory Slots 4×240pin
Memory Standard DDR2 800
Maximum Memory Supported 8GB
Channel Supported Dual Channel
Expansion Slots
PCI Express x16 2 (SLI mode: x8, x8)
PCI Express x1 1
PCI Slots 2
Storage Devices
PATA 2 x ATA100 4 Dev. Max
SATA 3Gb/s 4
SATA RAID 0/1/0+1/5
Onboard Video
Onboard Video Chipset None
Onboard Audio
Audio Chipset Realtek ALC883
Audio Channels 6 Channels
Onboard LAN
LAN Chipset Marvell 88E1116
Max LAN Speed 10/100/1000Mbps
Rear Panel Ports
PS/2 2
